Carbon steel pipe,Carbon Seamless Steel Pipe,Carbon Steel Welded Pipe,ERW welded steel pipe,SSAW welded steel pipe ,LSAW welded steel pipe
OD: 13.72-4064mm; WT: 13.72-4064mm ;LENGTH: 0.5mtr-20mtr
ASTM A53 B, ASTM A106 Gr. B, ASTM A179, ASTM A192, ASTM A333 and API 5L Gr B to X70
For conveying gas, water and oil either in the oil or natural gas industries
|
| |
▇ ▍ Description
Carbon steel pipes include seamless and welded pipes.
Seamless steel pipes are made from a round and robust piece of steel known as a billet. The billet has to be heated first, then stretched and finally pushed or rolled over a frame or form until the pipe is hollow.
Welded steel pipes are made from steel plates and steel strips. These strips and plates are made by moving steel loops and coils with a proper thickness gauge to form a leveled material. The flat leveled material is then measured and cut to the desired lengths.
Carbon Steel Pipe for Mineral Slurry
Mineral and slurry pipe is for the line pipe that applied in mining industries. A slurry pipeline is designated to transmit ores (Iron, Coal materials), or the industry mining waste, we called the pipeline as taillings. And generally these steel pipes connected in a long distances. Above materials mixed with water, we call slurry. People will use pumps to transport to the final destination then water will be filtered out. Since slurry contained different materials some with abrasive properties, so the pipe could be coated with 3PE, FBE layers to against from corrosion.
Both carbon steel pipe in seamless or welded could be used for the transmission of the slurry. So there is a wide range of material and standards available options to suit for the special working conditions.
What is most common used material for the mineral and slurry pipe. ASTM A106 pipe and ASTM A53 pipe.
ASTM A106 pipe
ASTM 106 pipe refers to the carbon steel pipe manufactured in hot rolled or cold drawn (rolled) seamless. ASTM A106 standard specification covers the seamless pipe that applied in high temperature services. As a result, it could used to carry the fluids (water, oil and gas, slurry), it is an important material for mining industries.
ASTM A53 pipe
ASTM A53 pipe covers welded and seamless steel pipe, in carbon black material and some cases in hot dipped galvanized (zinc coated). This is a basic pipe material, and it’s performances and prices also similar to ASTM A106B, or API 5L B. (We saw some pipes that they these three standards marked, call “Three standards steel pipe” ). So we say A53 pipe also is widely used in mining and slurry services.
Carbon Steel Pipes & Tubes Chemical Composition
| Sizes (Seamless) | 1/2”ND - 60^ NB |
| Sizes(ERW) | 12”NB- 24”NB |
| Sizes(SSAW) | 16”NB - 100NB |
| Wall Thickness available | schedule 20 - Schedule xXs (heavier on request) up to 250 mm thk |
Carbon Steel Pipe and Tube Mechanical Property
| Grade A | Grade B | Grade C | |
| Tensile strength,min,psi (MPa) | 48,000(330) | 60000 (415) | 7o,000(485) |
| Yield strength, min, psi (MPa) | 30,000 (205) | 35,000 (240) | 40,000(275) |
Dimension Tolerance of Carbon Steel Seamless Pipe
| TYPE | OD | Thickness |
| SEAMLESS | 114 inch~ 36 inch | 1.25mm ~ 50mm |
| ERW | 1/8 inch ~ 24 inch | Max 26.5mm |
| LSAW | 219mm - 3120mm | 3mm - 25mm |
| SSAW | 16 inch ~ 64 inch | 3mm ~ 25mm |
▇ ▍ Dimension of Carbon Steel Pipe
▇ ▍Application
Carbon steel pipe is versatile and useful for a variety of applications. Some of the most common uses of carbon steel piping are:
Building foundations
Transporting natural gases or oil
Boiler and condenser tubes
Transporting wastewater
Chemical Processing
High-pressure applications
Transporting sewage
Bollard construction
Shipbuilding
Shoring
Trash enclosures
Distillers
OEM applications
▇ ▍Process of Carbon Steel Pipe
▇ ▍ Description
Carbon steel pipes include seamless and welded pipes.
Seamless steel pipes are made from a round and robust piece of steel known as a billet. The billet has to be heated first, then stretched and finally pushed or rolled over a frame or form until the pipe is hollow.
Welded steel pipes are made from steel plates and steel strips. These strips and plates are made by moving steel loops and coils with a proper thickness gauge to form a leveled material. The flat leveled material is then measured and cut to the desired lengths.
Carbon Steel Pipe for Mineral Slurry
Mineral and slurry pipe is for the line pipe that applied in mining industries. A slurry pipeline is designated to transmit ores (Iron, Coal materials), or the industry mining waste, we called the pipeline as taillings. And generally these steel pipes connected in a long distances. Above materials mixed with water, we call slurry. People will use pumps to transport to the final destination then water will be filtered out. Since slurry contained different materials some with abrasive properties, so the pipe could be coated with 3PE, FBE layers to against from corrosion.
Both carbon steel pipe in seamless or welded could be used for the transmission of the slurry. So there is a wide range of material and standards available options to suit for the special working conditions.
What is most common used material for the mineral and slurry pipe. ASTM A106 pipe and ASTM A53 pipe.
ASTM A106 pipe
ASTM 106 pipe refers to the carbon steel pipe manufactured in hot rolled or cold drawn (rolled) seamless. ASTM A106 standard specification covers the seamless pipe that applied in high temperature services. As a result, it could used to carry the fluids (water, oil and gas, slurry), it is an important material for mining industries.
ASTM A53 pipe
ASTM A53 pipe covers welded and seamless steel pipe, in carbon black material and some cases in hot dipped galvanized (zinc coated). This is a basic pipe material, and it’s performances and prices also similar to ASTM A106B, or API 5L B. (We saw some pipes that they these three standards marked, call “Three standards steel pipe” ). So we say A53 pipe also is widely used in mining and slurry services.
Carbon Steel Pipes & Tubes Chemical Composition
| Sizes (Seamless) | 1/2”ND - 60^ NB |
| Sizes(ERW) | 12”NB- 24”NB |
| Sizes(SSAW) | 16”NB - 100NB |
| Wall Thickness available | schedule 20 - Schedule xXs (heavier on request) up to 250 mm thk |
Carbon Steel Pipe and Tube Mechanical Property
| Grade A | Grade B | Grade C | |
| Tensile strength,min,psi (MPa) | 48,000(330) | 60000 (415) | 7o,000(485) |
| Yield strength, min, psi (MPa) | 30,000 (205) | 35,000 (240) | 40,000(275) |
Dimension Tolerance of Carbon Steel Seamless Pipe
| TYPE | OD | Thickness |
| SEAMLESS | 114 inch~ 36 inch | 1.25mm ~ 50mm |
| ERW | 1/8 inch ~ 24 inch | Max 26.5mm |
| LSAW | 219mm - 3120mm | 3mm - 25mm |
| SSAW | 16 inch ~ 64 inch | 3mm ~ 25mm |
▇ ▍ Dimension of Carbon Steel Pipe
▇ ▍Application
Carbon steel pipe is versatile and useful for a variety of applications. Some of the most common uses of carbon steel piping are:
Building foundations
Transporting natural gases or oil
Boiler and condenser tubes
Transporting wastewater
Chemical Processing
High-pressure applications
Transporting sewage
Bollard construction
Shipbuilding
Shoring
Trash enclosures
Distillers
OEM applications
▇ ▍Process of Carbon Steel Pipe
